Product Description
Horst builds the ultimate, top-of-the-line snow blades for tractors and skid steer loaders.
Universal Skid Steer Style Quick-Attach Mounting Standard. Mounting options are available for most tractors. Please call 208-265-0415 with your requirements and we will be happy to assist.
Features:
* 30 - 80 HP Recommended or Max Operating Weight 10,000lbs
* 35 Degree Hydraulic Angle both directions
* Crossover Relief Valve - Provides protection against hidden obstacles by redirecting hydraulic pressure, swinging the blade around hazards.
* Optimized Mould Board Profile - Precision engineered curve rolls and folds snow. This reduces, sticking, side tracking and spill over.
* Quick-tach or direct fit to accept most makes of loaders
* 30" High moldboard
* Replaceable, Reversible Cutting Edge - Our cutting edges are designed to be easily replaceable and are reversible to give you twice the life.
* Adjustable Skids Shoe made of AR400 - Allow you to set cutting depth for optimum performance and prolonged cutting edge life.
* Spring-Trip Cutting Edge - Allows cutting edge to trip back if struck by hidden object limiting damage.
* Lateral Float - Allows blade to follow ground contours for better clearing performance.
* Hydraulic hoses/connectors optional
Universal Skid Steer Style Quick-Attach Mounting Standard. Mounting options are available for most tractors. Please call 208-265-0415 with your requirements and we will be happy to assist.
Features:
* 30 - 80 HP Recommended or Max Operating Weight 10,000lbs
* 35 Degree Hydraulic Angle both directions
* Crossover Relief Valve - Provides protection against hidden obstacles by redirecting hydraulic pressure, swinging the blade around hazards.
* Optimized Mould Board Profile - Precision engineered curve rolls and folds snow. This reduces, sticking, side tracking and spill over.
* Quick-tach or direct fit to accept most makes of loaders
* 30" High moldboard
* Replaceable, Reversible Cutting Edge - Our cutting edges are designed to be easily replaceable and are reversible to give you twice the life.
* Adjustable Skids Shoe made of AR400 - Allow you to set cutting depth for optimum performance and prolonged cutting edge life.
* Spring-Trip Cutting Edge - Allows cutting edge to trip back if struck by hidden object limiting damage.
* Lateral Float - Allows blade to follow ground contours for better clearing performance.
* Hydraulic hoses/connectors optional
Specifications
| Model | SB30007 |
| Manufacturer | Horst Welding |
| Product Manual | |
| Product Brochure | |
| Product Video | http://www.hlasnow.com/video.php |
| Weight | 900.0000 |
| Recommended Horsepower | 50 - 80 HP; 10,000 lbs. Max Operating Weight |
| Overall Width | 84 inches (7 feet; 213.4 cm) |
| Working Width | 84 inches (7 feet; 213.4 cm) |
| Moldboard Height | 30" |
| Angle Adjustment | 35 Degree Hydraulic Angle Either Direction Standard (less hoses/couplers) |
| Tilt Angle | Adjustable Lateral Float |
| Skid Shoes | AR400 Steel Adjustable and Replaceable, Included |
| Cutting Edge | Spring Trip Cutting Edge, Bolt-On, Reversible, Replaceable, Included |
| Hitch Connection Type | Standard Universal-Style Skid Steer Quick-Attach |
| Color | Yellow |
