Product Description
* Highly engineered & rugged gearbox .
* Front & rear tractor mounting.
* 4 rubber swivel tires to guarantee a perfectly level cut.
* Floating 3 point linkage, cat. 1.
* 10 gauge reinforced mower deck.
* Stamped steel reinforced wheel arm attached by 5 bolts for maintaining a consistent cutting height.
* Stamped steel wheel yokes.
* Cutting heights: from 1" to 4".
* Spindle shafts greased from the top for easy service.
* Heavy duty reinforced belt (BX).
* Heavy duty, one piece, balanced steel pulleys.
* Heavy duty shielded PTO shaft (1 3/8" ASAE cat. 2).
* High blade tip speed.
* Precise blade overlap.
* Front & rear tractor mounting.
* 4 rubber swivel tires to guarantee a perfectly level cut.
* Floating 3 point linkage, cat. 1.
* 10 gauge reinforced mower deck.
* Stamped steel reinforced wheel arm attached by 5 bolts for maintaining a consistent cutting height.
* Stamped steel wheel yokes.
* Cutting heights: from 1" to 4".
* Spindle shafts greased from the top for easy service.
* Heavy duty reinforced belt (BX).
* Heavy duty, one piece, balanced steel pulleys.
* Heavy duty shielded PTO shaft (1 3/8" ASAE cat. 2).
* High blade tip speed.
* Precise blade overlap.
Specifications
| Model | C30-RD4H |
| Manufacturer | Befco |
| Product Manual | |
| Weight | 340.0000 |
| Recommended Horsepower | 16 - 30 HP (12 - 22 KW) |
| Overall Width | 51" |
| Working Width | 48" (4 feet; 122 cm) |
| Deck Thickness | 10 Gauge Reinforced Mower Deck |
| Cutting Height | 1" - 4" (2.54 - 10.16 cm) |
| Blade Tip Speed | 13,188 ft/min |
| Rotor RPM | 3,037 RPM |
| Hitch Connection Type | Category 1, 3-Point Hitch, Quick-Hitch Compatible |
| PTO Speed | 540 RPM Standard; 1000 & 2000 RPM Optional |
| Color | Red |
