Product Description
Oversized 10-micron in-tank filter protects system from contamination while maximizing performance.
3,000 psi pressure relief valve protects system components from pressure spikes.
Convenient sight gauge allows for quick and easy checking of oil level.
Category 1 & 2 Hitch is also quick-hitch compatible.
25 gallon, heavy-duty, 11 gauge steel tank equipped with internal baffle that helps cool and condition the oil.
Heavy-duty Eaton industrial gearbox and pump maximize the flow rate and pressure, generating 3,000 psi.
1 1/2" inlet hose maximizes unrestricted flow of oil while preventing pump cavitation.
Convenient, 3-position storage legs allow for easy hookup and storage.
Conveniently-located drain hole allows for easy changing of oil.
Built-in mounting brackets for optional Oil Cooler.
Standard 3/4" hoses are rated for 3,000 psi from pump to front of loader.
Optional high-capacity oil cooler maintains proper oil temperature with low pressure loss, extending the life of components.
54 - 75 PTO HP Range Produces 24 GPM Hydraulic Flow @ 3000 psi.
3,000 psi pressure relief valve protects system components from pressure spikes.
Convenient sight gauge allows for quick and easy checking of oil level.
Category 1 & 2 Hitch is also quick-hitch compatible.
25 gallon, heavy-duty, 11 gauge steel tank equipped with internal baffle that helps cool and condition the oil.
Heavy-duty Eaton industrial gearbox and pump maximize the flow rate and pressure, generating 3,000 psi.
1 1/2" inlet hose maximizes unrestricted flow of oil while preventing pump cavitation.
Convenient, 3-position storage legs allow for easy hookup and storage.
Conveniently-located drain hole allows for easy changing of oil.
Built-in mounting brackets for optional Oil Cooler.
Standard 3/4" hoses are rated for 3,000 psi from pump to front of loader.
Optional high-capacity oil cooler maintains proper oil temperature with low pressure loss, extending the life of components.
54 - 75 PTO HP Range Produces 24 GPM Hydraulic Flow @ 3000 psi.
Specifications
| Model | HP24 |
| Manufacturer | Erskine |
| Product Brochure | |
| Weight | 75.0000 |
| Horesepower Requirement | 54 - 75 PTO HP Range Produces 24 GPM Hydraulic Flow @ 3000 psi |
| Color | Black |
