Product Description
Heavy Duty Rear Tractor Blade
Complete with Category I and quick hitch
compatible hookup. Features a super-duty
reinforced upper frame and rated for 20-60
HP tractors.
Replaceable blades are 6" tall by 1/2" thick and attached to the 1/4" thick by 14-1/2" high moldboard blade.
Blade has 5 front settings and 5 reverse settings on the adjustment wheel. Also, this heavy-duty grader blade can be offset up to 12" either direction with a 7-degree tilt (blade oscillation) in either direction.
Durable, corrosion-resistant powder coat gray.
Features a support stand allowing for easier hookup.
Complete with Category I and quick hitch
compatible hookup. Features a super-duty
reinforced upper frame and rated for 20-60
HP tractors.
Replaceable blades are 6" tall by 1/2" thick and attached to the 1/4" thick by 14-1/2" high moldboard blade.
Blade has 5 front settings and 5 reverse settings on the adjustment wheel. Also, this heavy-duty grader blade can be offset up to 12" either direction with a 7-degree tilt (blade oscillation) in either direction.
Durable, corrosion-resistant powder coat gray.
Features a support stand allowing for easier hookup.
Specifications
| Model | GBHDGR5 |
| Manufacturer | Tarter |
| Weight | 307.0000 |
| Recommended Horsepower | 20 - 60 HP |
| Overall Width | 60" (5 feet; 152 cm) |
| Working Width | 60" (5 feet; 152 cm) |
| Moldboard Height | 15 1/2" |
| Cutting Edge | 1/2” x 6” Bolt-On / Reversible / Replaceable, Included |
| Angle Adjustment | 5 forward angles; 5 reverse angles; |
| Tilt Angle | 7 degree tilt (blade oscillation) in either direction |
| Skid Shoes | N/A |
| Hitch Connection Type | Category 1, 3-Point Hitch, Quick-Hitch Compatible |
| Color | Gray |
