Product Description
Horst builds the ultimate, top-of-the-line snow blades for tractors and skid steer loaders.
The Snow Wing series of blades gives you the option to convert from a box blade to straight blade and get that extra clearing width on the fly. But it doesn’t stop there: The endplates are hydraulically-controlled and equipped with industry-proven rotary actuators, giving limitless control within the massive 180 degree rotation. This means you can use your blade on an angle with one end open and the other parallel to the direction you are driving. Get closer to buildings and parking stones without risking damage. Then rotate the endplates into a reverse box blade and drag the snow away for full clearing in the tightest of spaces.
Universal Skid Steer Mounting Standard. Mounting options are available for most tractors. Please contact us with your requirements.
Features:
* Hydraulic actuators on wing pivots
* Infinite wing adjustment from 0 degrees to 180 degrees
* 50-85 HP or Max Operating Weight 10,000lbs
* 6' Width with Wings Retracted
* 11' Width with Wings Extended
* Wings are 30" deep x 30" high
* 35 Degree Angle
* Crossover Relief Valve
* Quick-tach or direct fit to accept most makes of loaders
* 30" High moldboard
* Reversible Cutting Edge
* Skid Shoe Material AR400
* Spring-trip Cutting Edge
* Hoses/connectors optional
The Snow Wing series of blades gives you the option to convert from a box blade to straight blade and get that extra clearing width on the fly. But it doesn’t stop there: The endplates are hydraulically-controlled and equipped with industry-proven rotary actuators, giving limitless control within the massive 180 degree rotation. This means you can use your blade on an angle with one end open and the other parallel to the direction you are driving. Get closer to buildings and parking stones without risking damage. Then rotate the endplates into a reverse box blade and drag the snow away for full clearing in the tightest of spaces.
Universal Skid Steer Mounting Standard. Mounting options are available for most tractors. Please contact us with your requirements.
Features:
* Hydraulic actuators on wing pivots
* Infinite wing adjustment from 0 degrees to 180 degrees
* 50-85 HP or Max Operating Weight 10,000lbs
* 6' Width with Wings Retracted
* 11' Width with Wings Extended
* Wings are 30" deep x 30" high
* 35 Degree Angle
* Crossover Relief Valve
* Quick-tach or direct fit to accept most makes of loaders
* 30" High moldboard
* Reversible Cutting Edge
* Skid Shoe Material AR400
* Spring-trip Cutting Edge
* Hoses/connectors optional
Specifications
| Model | SB3200W813 |
| Manufacturer | Horst Welding |
| Product Manual | |
| Product Brochure | |
| Product Video | http://www.horstwelding.com/video_gallery.php?media=SnowWing |
| Weight | 1420.0000 |
| Recommended Horsepower | 50 - 85 HP; 10,000 lb. max operating weight |
| Working Width | Wings Retracted: 96 inches (8 feet; 243.8 cm); Wings Extended: 156 inches (13 feet; 396.2 cm) |
| Moldboard Height | 30" |
| Angle Adjustment | 35 Degree Hydraulic Angle Either Direction Standard (less hoses/couplers) |
| Tilt Angle | Lateral Float |
| Skid Shoes | AR400 Steel Adjustable and Replaceable, Included |
| Cutting Edge | Spring Trip Cutting Edge, Bolt-On, Reversible, Replaceable, Included |
| Hitch Connection Type | Standard Universal-Style Skid Steer Quick-Attach |
| Color | Yellow |
