Product Description
The 38 series are designed for 540 RPM and a maximum of 100 HP. All models have two 14 inch augers and a 30 inch diameter fan. The hitch is standard Category II three point. The end plates are 3/16 thick and all four corners of the housing are well braced. Standard equipment includes a hydraulic spout rotating kit, PTO shaft, and all pins. Models 738 and 838 have higher housings, and Model 838 has an option for four skid shoes. Other options include the Drift Buster and a curb wear plate.
Specifications
| Model | 738 |
| Manufacturer | Lorenz |
| Weight | 1150.0000 |
| Recommended Horsepower | Up to 100 Horsepower Maximum |
| Overall Width | 84 inches (7 feet; 213 cm) |
| Working Width | 84 inches (7 feet; 213 cm) |
| Auger Diameter | 14" Double Augers |
| Fan Diameter | 30" |
| Cutting Edge | Bolt-On, Replaceable, Included |
| Skid Shoes | Adjustable and Replaceable, Included |
| Spout Rotator | Hydraulic Standard |
| Spout Deflector | Manual Standard, Hydraulic or Electric Optional |
| Hitch Connection Type | Category 2, 3-Point Hitch |
| PTO Speed | 540 RPM |
| Color | Yellow |
