Product Description
CALL 208-265-0415 FOR OUR BELOW LIST PRICE ON THIS ERSKINE PRODUCT!
Made In USA.
Proven Performance, Versatility & Reliability...
With the Erskine Front Mount Hydraulic Snow Blower / Power Pack combo, there is no need to remove your loader. Switch from one attachment to the next in seconds. Erskine's experienced industry engineers are able to perfectly match the Hydraulic Snowblower and Power Unit to work universally on any tractor and loader that has the Skid Steer Loader Attachment Carrier and is within the unit’s specified power range. Recognized in the industry as a leader and innovator of quality, value-added snowblowers. Over 63 years of proven performance.
Snow Blower Features:
* The durable new 5/8" x 6" cutting edge design provides significantly more surface area, allowing it to act as a skid shoe and extending the life of the cutting edge. You can now achieve the desired cutting effect simply by controlling the angle of the snow blower.
* Shortened end plates allow the auger to lead. In hard packed snow, the auger makes contact first and starts chewing it up for maximum effectiveness and reduced resistance.
* The cut back top design provides better visibility and allows snow to fall into the auger to be blown rather than slide off the back of the snowblower.
* The new cutting edge extends beyond the end plates, adding wear bar protection.
* Universal Quick Attach Plates fit most skid steers.
* Direct drive hydraulic auger.
* Replaceable bolt-on high carbon-steel cutting edge.
* Durable, super slippery chute prevents plugging.
* Hydraulic relief – no shear pins.
* Hydraulic control valve with electric solenoid controls all chute functions.
Hydraulic Power Unit Features:
* 54 - 75 PTO HP Range Produces 24 GPM Hydraulic Flow @ 3000 psi.
* Oversized 10-micron in-tank filter protects system from contamination while maximizing performance.
* 3,000 psi pressure relief valve protects system components from pressure spikes.
* Convenient sight gauge allows for quick and easy checking of oil level.
* Category 1 & 2 Hitch is also quick-hitch compatible.
* 25 gallon, heavy-duty, 11 gauge steel tank equipped with internal baffle that helps cool and condition the oil.
* Heavy-duty Eaton industrial gearbox and pump maximize the flow rate and pressure, generating 3,000 psi.
* 1 1/2" inlet hose maximizes unrestricted flow of oil while preventing pump cavitation.
* Convenient, 3-position storage legs allow for easy hookup and storage.
* Conveniently-located drain hole allows for easy changing of oil.
* Built-in mounting brackets for optional Oil Cooler.
* Optional high-capacity oil cooler maintains proper oil temperature with low pressure loss, extending the life of components.
Made In USA.
Proven Performance, Versatility & Reliability...
With the Erskine Front Mount Hydraulic Snow Blower / Power Pack combo, there is no need to remove your loader. Switch from one attachment to the next in seconds. Erskine's experienced industry engineers are able to perfectly match the Hydraulic Snowblower and Power Unit to work universally on any tractor and loader that has the Skid Steer Loader Attachment Carrier and is within the unit’s specified power range. Recognized in the industry as a leader and innovator of quality, value-added snowblowers. Over 63 years of proven performance.
Snow Blower Features:
* The durable new 5/8" x 6" cutting edge design provides significantly more surface area, allowing it to act as a skid shoe and extending the life of the cutting edge. You can now achieve the desired cutting effect simply by controlling the angle of the snow blower.
* Shortened end plates allow the auger to lead. In hard packed snow, the auger makes contact first and starts chewing it up for maximum effectiveness and reduced resistance.
* The cut back top design provides better visibility and allows snow to fall into the auger to be blown rather than slide off the back of the snowblower.
* The new cutting edge extends beyond the end plates, adding wear bar protection.
* Universal Quick Attach Plates fit most skid steers.
* Direct drive hydraulic auger.
* Replaceable bolt-on high carbon-steel cutting edge.
* Durable, super slippery chute prevents plugging.
* Hydraulic relief – no shear pins.
* Hydraulic control valve with electric solenoid controls all chute functions.
Hydraulic Power Unit Features:
* 54 - 75 PTO HP Range Produces 24 GPM Hydraulic Flow @ 3000 psi.
* Oversized 10-micron in-tank filter protects system from contamination while maximizing performance.
* 3,000 psi pressure relief valve protects system components from pressure spikes.
* Convenient sight gauge allows for quick and easy checking of oil level.
* Category 1 & 2 Hitch is also quick-hitch compatible.
* 25 gallon, heavy-duty, 11 gauge steel tank equipped with internal baffle that helps cool and condition the oil.
* Heavy-duty Eaton industrial gearbox and pump maximize the flow rate and pressure, generating 3,000 psi.
* 1 1/2" inlet hose maximizes unrestricted flow of oil while preventing pump cavitation.
* Convenient, 3-position storage legs allow for easy hookup and storage.
* Conveniently-located drain hole allows for easy changing of oil.
* Built-in mounting brackets for optional Oil Cooler.
* Optional high-capacity oil cooler maintains proper oil temperature with low pressure loss, extending the life of components.
Specifications
| Model | ES2010-79/HP24 |
| Manufacturer | Erskine |
| Weight | 1150.0000 |
| Overall Width | 79 inches (200.7 cm) |
| Working Width | 79 inches (200.7 cm) |
| Cutting Height | 29" |
| Auger Diameter | 16" Single |
| Fan Diameter | 20" 4-Blade Fan |
| Hydraulic Flow Required | 20 - 25 GPM @ 3000 psi |
| Skid Shoes | Optional |
| Spout Deflector | Hydraulic Standard |
| Spout Rotator | Hydraulic Standard |
| Cutting Edge | 5/8" x 6" Bolt-On |
| Hitch Connection Type | Standard Universal-Style Skid Steer Quick-Attach |
| Color | Black |
