120" Bison Super Heavy Duty 3-Point Tractor Rear Blade Model NVHL-300XHD
In Stock
SKU
ELL-BIS-NVHL-300XHD
Compare at:
$5,826.00
Our Price:
$5,535.00
| Compare at | : | $5,826.00 | |
|---|---|---|---|
| Our Price | : | $5,535.00 | |
| SKU | : | ELL-BIS-NVHL-300XHD | |
| Identifier | : | BIS-1051 | |
| Availability | : |
Ships in approximately 3-5 Business Days. May be subject to unexpected delays. |
|
Questions: Call 208-265-0415 or email sales@idahoimplement.com
If you need a super heavy duty tractor blade capable of handling the most extreme working conditions, look no further. The Bison Super Heavy Duty Hydraulic-Capable NVHL blades are precision engineered to address a wide range of material handling work...from landscaping to heavy duty dam-building jobs.
Bison Blades offer rugged construction & outstanding performance at unmatched prices. The NVHL-series blades are designed for tractors up to 150HP.
Featuring superior craftsmanship and innovative designs. The Bison extra long boom allows full angling of moldboard without the chance of damaging tractor tires. Ditching and terracing jobs can be accomplished quickly and easily with optional hydraulic tilt adjustment. 360º Total swing angle. The 1/2” x 6” grader-type steel cutting edge is reversible, featuring bevels on both edges for twice the work life, and replaceable for even greater functionality.
An important factor in the performance of the rear blade is the precision-formed moldboard with the exact curvature necessary to achieve maximum penetration. This added precision allows rear blades to cut and roll the soil rather than dragging, which saves time, horsepower, and fuel. The NVHL models offer even more, such as fully hydraulic angle, tilt, and offset movements (manual adjustments standard).
Optional Dual Tail-Wheel Assembly simplifies your grading jobs and increases your landscaping work efficiency.
You will not find a better built, heavier blade for anywhere near the cost of a quality Bison blade.
* Assembly Required.
Bison Blades offer rugged construction & outstanding performance at unmatched prices. The NVHL-series blades are designed for tractors up to 150HP.
Featuring superior craftsmanship and innovative designs. The Bison extra long boom allows full angling of moldboard without the chance of damaging tractor tires. Ditching and terracing jobs can be accomplished quickly and easily with optional hydraulic tilt adjustment. 360º Total swing angle. The 1/2” x 6” grader-type steel cutting edge is reversible, featuring bevels on both edges for twice the work life, and replaceable for even greater functionality.
An important factor in the performance of the rear blade is the precision-formed moldboard with the exact curvature necessary to achieve maximum penetration. This added precision allows rear blades to cut and roll the soil rather than dragging, which saves time, horsepower, and fuel. The NVHL models offer even more, such as fully hydraulic angle, tilt, and offset movements (manual adjustments standard).
Optional Dual Tail-Wheel Assembly simplifies your grading jobs and increases your landscaping work efficiency.
You will not find a better built, heavier blade for anywhere near the cost of a quality Bison blade.
* Assembly Required.
| SKU | ELL-BIS-NVHL-300XHD |
|---|---|
| Weight | 1550 lbs |
| Identifier | BIS-1051 |
| Model | NVHL-300XHD |
| Horsepower Recommended | 80 - 150 HP (59.7 - 111.9 KW) |
| Width - Overall | 120" (10 Feet; 305 cm) |
| Width - Working | 120" (10 Feet; 305 cm) |
| Width - Fully Angled | 116" (295 cm) @15º; 104 Inches (264 cm) @ 30º; 85 Inches (216 cm) @ 45º |
| Moldboard | 19" Tall (48 cm) x 5/16" Thick (.8 cm) |
| Cutting Edge | Bolt-On, Reversible, Replaceable, Included |
| Angle | Manual Angle, 15º, 30º and 45º Left or Right; Forward and Reverse; 360º Rotation; Hydraulic Optional |
| Tilt | Manual Pinset Tilt Adjustment - Up to 23-Degrees Up or Down; Hydraulic Optional |
| Offset | Manual Pinset Offset Adjustment - Up to 18" Left or Right; Hydraulic Optional |
| Skid Shoes | Optional |
| End Plates | Optional |
| Hitch Connection Type | Category 2/3, 3-Point Hitch |
| Parking Stand | Included Standard |
| Color | Black |
| Manufacturer | Bison |
